| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | AIJR-16A |
| Minimum Order Quantity: | 1 SET IEC60851-3 Winding Test Instrument |
|---|---|
| الأسعار: | قابل للتفاوض |
| Packaging Details: | One Plywood case for IEC60851-3 Winding Test Instrument |
| وقت التسليم: | 90 يوما |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 10 مجموعات/شهر |
| اختبار معيار: | GB / T4074.3-2008 ، IEC60851-3 | سرعة متعرج: | 100 ± 10r / دقيقة |
|---|---|---|---|
| عدد لفات اللف: | 1 ~ 999r اختياري | لون: | أزرق |
| عرض: | قاد | لغة: | إنجليزي |
| قوة الإدخال: | AC220V ± 10 ٪ 50Hz | استهلاك الطاقة: | <100 واط |
| البعد العام: | 640 × 345 × 350 مم | وزن: | 40 كجم |
Performance Characteristics
1.Executive standard: GB/T4074.3-2008,IEC60851-3
2.The winding test instrument is suitable for measuring the flexibility, adhesiveness, thermal shock and other performances of the film of enameled round wire with nominal conductor diameter below 1.600mm;
3.Used with JRB-16 enameled round wire winding test bar;
4.This winding test instrument can set any number of winding turns;
5.LED would automatically display and record the number of winding turns.
6.The application of high-end SCM control allows for simple operation, steady and stable performance.
Major Technical Parameters
| Winding speed | 100±10r/min |
| Number of winding turns | 1~999r optional |
| Input power | AC220V±10% 50Hz |
| Power consumption | ≤100W |
| Overall dimensions | L×W×H 640×345×350mm |
| Weight | 40kg |
Preparation of weights:
Mini-weight hook 0.1N×1, mini-weight 0.1N×2, 0.2N×1 and 0.5N×1
Large-weight hook 1N×1, large-weight 1N×2, 2N×1 and 5N×3
