| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | FVT |
| Minimum Order Quantity: | 1 SET ASTM D3014A Tester |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حالة الخشب الرقائقي |
| وقت التسليم: | 30 يوما |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 50 مجموعة في الشهر |
| Test standard: | ASTM D3014A,GB 8624,GB/T 8333 | Test object: | Rigid Thermoset Cellular Plastics |
|---|---|---|---|
| البعد: | 420 ملم (غ) × 350 ملم (د) × 520 ملم (ه) | وزن: | 15 كجم |
| Power supply: | 220 V,50 Amps | ضمان: | 1 سنة |
| لون: | أسود | Gas: | Industrial propane |
Introduction:
This Vertical Flammability Tester is suitable for the flame height, burning time and loss of mass of Rigid Thermoset Cellular Plastics in a vertical position. It meets the standards of GB/T 8333 and ASTM D3014A.
Main features:
1. ASTM D3014A Vertical Flammability Tester is equipped with Bunsen burner, which can provide a test temperature at 900℃;
2. The thermocouple can be moved manually to avoid damage caused by prolonged exposure to flame;
3. The test can be completed with one button, and the burner adopts automatic driving mode;
4. Through the test steel ruler, the burning length can be displayed;
5. The gas flow can be adjusted and cut off automatically;
6. The test box is treated with Teflon to avoid corrosion.
Specifications of ASTM D3014A Vertical Flammability Tester:
| 1 | Power supply | 220V,50HZ |
| 2 | Dimension | 420 mm (W) x 350 mm (D) x 520 mm (H) |
| 3 | Weight | 15KG |
| 4 | Environmental temperature | 10°C ~ 35°C |
| 5 | Installation area | with fume hood |
| 6 | Gas | Industrial propane |
