| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| رقم الموديل: | F8095 |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | لوح صلب |
| وقت التسليم: | 30 يوما |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| نطاق التحكم في درجة الحرارة: | 20 ~ 150 درجة مئوية ± 2 درجة مئوية | طريقة التبريد: | ضاغط |
|---|---|---|---|
| مزود الطاقة: | AC220V / 50 هرتز | رن الضغط: | 7 ميجا باسكال ± 0.3 ميجا باسكال |
| عدد السكتات الدماغية: | 85,000 دورة | معدل السكتة الدماغية: | 1000 دورة/ساعة |
| اختبار معيار: | ايزو 4925 | ضمان: | 1 سنة |
Summary
This Stroke Simulation Measuring Equipment is suitable for evaluating the lubricating performance and material compatibility of brake fluid.
Under specified test requirements, a total of 85,000 stroke tests are conducted to observe the changes in relevant materials.
Main Features
1. One cast iron brake master cylinder, with a cylinder diameter of 28.58mm to 28.65mm, and an aluminum alloy piston with a diameter of 28.52mm to 28.55mm.
2. Three brake slave cylinders, with a cylinder diameter of 28.60mm to 28.66mm, and an aluminum alloy piston with a diameter of 28.52mm to 28.55mm.
3. A set of specialized pump body adjustment installation plates.
4. The main pipeline is made of uncoated steel pipe.
5. A standard driving mechanism capable of generating a working pressure of 8 Mpa.
6. Digital display of stroke rate with an adjustable device.
7. Radiation-free heating system.
8. Rubber cups that meet standard requirements.
9. Microcomputer temperature controller with digital display, temperature control range: 20~150℃±2℃, PT100 temperature sensor for high precision.
10. Pressure gauge displays working pressure, with a precision pressure regulating valve for adjustment, pressure: 7Mpa±0.3 Mpa.
11. Digital timer with audible alarm.
12. Fully enclosed compressor refrigeration, with gas circulation to reduce the temperature of the test chamber.
13. Integrated structure for easy operation.
Technical specifications
| 1 | Power supply | AC 220 V±10%, 50 Hz |
| 2 | Temperature control range | 20~150℃±2℃ |
| 3 | Cooling method | Compressor |
| 4 | Temperature control method | Digial PID temperature controller |
| 5 | Timing method | Digital timer |
| 6 | Alarming method | Buzzer |
| 7 | Pressure range | 7Mpa±0.3 Mpa |
| 8 | Pressure Control | Precision pressure regulating valve |
| 9 | Pressure Display | Precision pressure gauge |
| 10 | Stroke Rate | 1000 cycles/h |
| 11 | Stroke Count | 85,000 cycles |
