Summary
This Seal Compatibility Index Test Equipment is suitable for the determination of various petroleum products, but it is not suitable for the determination of water containing petroleum products.
Measure the inner diameter of the rubber ring with a conical gauge, then soak the rubber ring in the sample at a certain temperature for 24 hours, take it out for cooling, and measure the change of the rubber inner diameter with a conical gauge.
I. Main technical features
1.The air guide cooling system automatically starts to dissipate heat when the surface temperature of the instrument is too high;
2.The Seal Compatibility Index Test Equipment adopts Novel V-shaped door opening mode, fully transparent high-temperature resistant glass door;
3.Enamel liner is corrosion-resistant and easy to clean;
4.The box is equipped with fan circulation and lighting devices;
5.Standard alloy steel gauge is provided with this Seal Compatibility Index Tester;
6.Imported Omron PID temperature controller, digital display temperature, accuracy 0.1 ºC
7.Working range: room temperature ~ 100 ° C ± 1 ° C;
8.The Seal Compatibility Index Test Equipment has over temperature safety protection.
II. Main technical specifications
| 1 |
Applicable standard |
SH/T 0305,IP 278 |
| 2 |
Heating method |
Stainless steel electrical heating tube |
| 3 |
Temperature control method |
Imported PID temperature controller |
| 4 |
Temperature control range |
RT~100 ºC |
| 5 |
Temperature control accuracy |
±1 ºC |
| 6 |
Working voltage |
10KV±2% |
| 7 |
Dimension |
600*600*650mm3 |
| 8 |
Weight |
40KG |
| 9 |
Total power |
1200W |
| 10 |
Power supply |
AC 220V±10%, 50 Hz |
