| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| رقم الموديل: | إيك-1743 |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| Packaging Details: | Corrosion Preventive Properties Tester packed in Plywood case |
| وقت التسليم: | 20 يومًا |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| اختبار معيار: | غب / T5018، أستم D1743 | وضع التدفئة: | حمام معدني |
|---|---|---|---|
| Timing mode and range: | Digital timer,0.01s～99h99m | سرعة المحرك: | 1450r / دقيقة |
| Power supply: | AC 220V ,50Hz | ضمان: | 1 سنة |
| لون: | فضي | وزن: | 18 كجم |
| نطاق التحكم في درجة الحرارة: | المحيط ～ 150 ℃ ± 0.1 ℃ |
Coat the sample on a new bearing and run it for 60 seconds under a light thrust load to distribute the grease as it is used. The bearing is stored for 48 hours at 52 degrees and 100% relative humidity, and then clean and inspect for signs of corrosion on the outer ring raceway of the bearing.
Main feature
◆The Corrosion Preventive Properties Tester is equipped with a set of mechanical greasers and a set of thrust loader;
◆Automatically control the running time, and automatically shut down when the test requirements are reached;
◆Bearing meets standard requirements;
◆Digital display of working hours.
Technical specifications
| Model | AIC-1743 |
| Applicable standard | GB/T5018,ASTM D1743 |
| Motor speed | 1450r/min |
| Power supply | AC220V 50HZ |
| Total power | 800W |
| Dimension | 360*480*550mm |
| Weight | 18KG |
Accessories List
| No. | Name | Specification | Quantity |
| 1 | Corrosion Preventive Properties Tester | 1 Set | |
| 2 | Shaft loading accessories | 1 Set | |
| 3 | Mechanical greaser | 1 Set | |
| 4 | Pliers | 1 PC | |
| 5 | Standard bearing | 1 PC | |
| 6 | Fuse | 20(A) | 4 PCS |
| 7 | Injector | 100ml | 1 PC |
| 8 | Silicon tube | Φ4 | 1 Root |
| 9 | Manual book | 1 Copy |
