| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | AIC-943 |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | لوح صلب |
| وقت التسليم: | 20 يومًا |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| Test Standard: | ASTM D943,GB/T12581 | Temperature range: | ambient~120℃±0.1℃ |
|---|---|---|---|
| Dimensions: | 630*710*930mm | مزود الطاقة: | 220V 50Hz |
| Keyword: | Oxidation Characteristics Tester | ضمان: | 1 سنة |
| وزن: | 50 كجم | Flow range: | 0～200ML/H |
| استهلاك الطاقة: | 2400W | طريقة التوقيت: | مؤقت رقمي |
Summary
◆ The Oxidation Stability Analyzer adopts Metal bath heating,safe and environment-friendly.
◆ Mic-computer temperature controller,digital display,accuracy ±0.1℃, PT100 sensor.
◆ Precise flow meter controls air flow.
◆ The Oxidation Stability Analyzer can do 6 tests simultaneously,every 3 samples for two groups.
◆ Working time is displayed digitally
◆ Glass tube as per standards
◆ Big power solid relay controlls temperature rising
◆ The Oxidation Stability Analyzer has function of Over-temperature alarming.
Technical Specifications
| Model | AIC-943 Oxidation Stability Analyzer for Inhibited Mineral Oils |
| Applicable standards | GB/T12581 ASTM D943 |
| Heating method | electrical heating rod |
| Temperature controlling range | ambient~120℃±0.1℃ |
| Temperature controlling method | imported digital PID temperature controller |
| Working units | 6 |
| Timing method | digital timer |
| Flow range | 0～200ML/H |
| Total power consumption | 2400W |
| Dimensions | 630*710*930mm |
| Weight | 50KG |
| Power supply | AC220V 50HZ |
