| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | SCT-I |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | لوح صلب |
| وقت التسليم: | 20 يومًا |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| Test standard: | ASTM D1266 | Test method: | Lamp method |
|---|---|---|---|
| وحدات العمل: | 5 أجهزة كمبيوتر | استهلاك الطاقة: | 150 واط |
| Size: | 380mm×320mm×600mm | الأسعار: | Cheap |
| مزود الطاقة: | AC220V ± 10 ٪ 50Hz | ضمان: | 1 سنة |
Summary
The sulphur content tester is designed and made as per the national standard of People's Republic of China GB/T380 Standard Test Method for Sulfur Content in Petroleum Products (Lamp Method). It is used to determine the sulfur content in light oils(such as gasoline,kerosene) which the Reid vapor pressure is not higher than 600mmHg as per GB/T380.
I. Main technical features
1. This sulphur content analyzer adopts small desktop structure. It can do determination for 5 samples at a time.
2. The lamp is located in fixed seat. The height and sucking rate for each can be adjusted independently.
3. Stainless steel material. Reasonable design and easy to clean.
| 1 | Power supply | AC 220 V ±10%, 50 Hz |
| 2 | Working units | Five independent groups |
| 3 | Electromagnet pum | Five groups of main pumps, one group of auxiliary pump(stir pump). |
| 4 | Vacuum pumping adjustment | It can be continuously adjusted by a potentiometer for each group |
| 5 | Lamp adjustment | It can be adjusted up and down. The adjustment range is not less than 15 mm |
| 6 | Test tube holder | Each holder can be adjusted independently. Its adjustment range is not less than 20 mm. |
| 7 | Ambient temperature | -10 ℃～ 40 ℃ |
| 8 | Relative humidity | ≤ 85% |
| 9 | Maximum power consumption | 150 W |
| 10 | Dimension | 380mm×320mm×600mm(including test vessels) |
| No. | Name | Unit | Qty | Memo |
| 1 | SCI-I Sulfur Content Tester (Lamp method) | Set | 1 | |
| 2 | Glass instrument for sulfur content test(Glass absorber, droplet collector, flue, burning lamp) | Set | 5 | |
| 3 | Stirring tube | Piece | 1 | Installed already |
| 4 | Glass bead | Packet | 1 | |
| 5 | 5A fuse (Ф5 × 20) | Piece | 2 | |
| 6 | Gasket for lamp (Lined in the rotation sheath of lamp to stop the lamp from moving) | Piece | 5 | |
| 7 | Cotton yarn (wick) | Meter | 0.5 | |
| 8 | Operation manual | Piece | 1 | |
| 9 | Quality certificate | Piece | 1 | |
| 10 | Product warranty card | Piece | 1 |
