| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | NF504 |
| Minimum Order Quantity: | 1 SET NFP 92-504 Speed of Spread of Flame Test Apparatus |
|---|---|
| الأسعار: | قابل للتفاوض |
| Packaging Details: | NFP 92-504 Speed of Spread of Flame Test Apparatus Packed in Plywood case |
| وقت التسليم: | 40 يومًا |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| اختبار معيار: | المخطط الوطني رقم 92-504 | مقاس: | 470mm ((W) X 470mm ((H) X 330mm ((D) |
|---|---|---|---|
| وزن: | 18 كجم | ضمان: | 1 سنة |
| لون: | أسود | مزود الطاقة: | 220 فولت ، 50 هرتز |
| Test object: | Building and Rail Materials | Function: | Speed of Spread of Flame Test |
Introduction
NF P 92-504 for the determination of horizontal flame spread rate of materials. This method also applies in other rapidly melting and testing without burning, or not achieve M1 ~ M3 material.
This speed of spread of flame test apparatus is intended to test a sample of a material under certain conditions to a heat source consisting of a gas igniter, and may trigger: sample fire and flame persistence test and flame spread and spread. The speed test is in accordance with the fire reaction performance test of French building materials and high-iron non-metallic materials.
Standard:
NFP 92-504 speed of spread of flame test.
Product parameters
1. The NFP 92-504 Speed of Spread of Flame Test Apparatus is applicable to French building materials and high-speed rail test standard NFP 92-504;
2. Using a standard burner, the sample is subjected to flame impact, and then the flame spread performance of the sample is observed;
3. U-shaped specimen holders with soft and hard materials at the same time;
4. The burner movement adopts a programmable controller, and the test time and the number of ignitions can be automatically controlled.
Installation requirements:
| 1 | Electrical requirements | 220V, 50HZ |
| 2 | Gas source requirements | propane and air compressor gas |
| 3 | Enviromental tempreature | 25±5°C |
| 4 | Installation place | fume hood placement |
| 5 | Dimension | 470mm(W)X 470mm(H)X 330mm(D) |
| 6 | Weight | 18KG |
