| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| رقم الموديل: | أ91 |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | لوح صلب |
| وقت التسليم: | 20 يومًا |
| شروط الدفع: | L/C ، T/T ، Western Union |
| القدرة على العرض: | 20 مجموعات شهريا |
| Test standards: | ASTM UOP960 | Application: | Measure Trace Oxygenated Hydrocarbon in Liquid Hydrocarbon Streams |
|---|---|---|---|
| طريقة الاختبار: | GC | ضمان: | 1 سنة |
| مزود الطاقة: | AC220V ± 10 ٪ 50Hz | Keyword: | UOP960 Gas Chromatagraph |
Flow chart of Measuring Trace Oxygenated Hydrocarbons in Naphtha
2 Configuration
| Item | CAT NO. | DESCRIPTION | QTY |
| 1 | G2091A | A91 Plus CG | 1 |
| 2 | G2011B | Software | 1 |
| 3 | 1790M | Start-up kit A(including sample injection port)) | |
| 4 | #210 | FID | 2 |
| 5 | #120 | SISL Capillary Injection Port (0~100 psi) | 1 |
| 6 | PN5.132.002 | One way PCM Pressure Control Module | 1 |
| 7 | #513 | Three automatic valves,with valve box heating and pipeline | 1 |
| 8 | #561 | Six way rotor valve | 2 |
| 9 | #450 | Independent heating column(at the back of FID detector) | 1 |
| 10 | #515 | Side Valve Box | 1 |
| 11 | #542 | Four way liquid injection valve(1.0ul volume,75C and 1000 psi max) | 1 |
| 12 | #360 | Liquid injection valve back pressure damping system assembly | 1 |
| 13 | ECM.7.342.001 | 2um stainless steel gas filter | 1 |
| 14 | #610 | Sample ring(0.5mL) | 1 |
| 15 | PN5.150.006 | Deoxidation trap | 1 |
| 16 | PN5.150.004 | Dewatering trap | 1 |
| 17 | PN5.150.005 | Dealkylation trap | 1 |
| 18 | Pipeline | Capillary column 1m*0.53 | 1 |
| 19 | Column 1 | 20m*530um ID*5um MXT-1,Restek Cat.No.71812 | 1 |
| 20 | Column 2 | 10m*530 u ID*10 uLowox | 1 |
| 21 | Column 3 | 30m*0.53 | 1 |
| 22 | Computer | Lenovo | 1 |
3.Spectrum
