| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| رقم الموديل: | فاز |
| الحد الأدنى لكمية: | 1 جهاز كمبيوتر |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حالة الخشب الرقائقي |
| وقت التسليم: | 10 أيام |
| شروط الدفع: | / تي تي، ويسترن يونيون |
| القدرة على العرض: | 1000 قطعة/شهر |
| Test standard: | ASTM D2419 | Oscillating cycle: | (180±2) times/min |
|---|---|---|---|
| Amplitude of cylinder: | 203mm±1.0mm | القوة المقدرة: | 130W |
| وزن: | 20 كجم | Power supply: | AC (220 ± 5%) V, 50Hz |
| Size: | 564mm×320mm×360mm | ضمان: | 1 سنة |
| 1 | Oscillating cycle | (180±2) times/min |
| 2 | Amplitude of cylinder | 203mm±1.0mm |
| 3 | Power supply | AC(220±10%)V,50Hz |
| 4 | Rated power | 130 W |
| 5 | Dimension of test cylinder | Inner diameter is 32mm±0.25mm. Length is 420mm |
| 6 | Flushing pipe | OD is 6mm±0.5 mm, ID is 4mm±0.2mm |
| 7 | Ambient temperature | ≤35℃ |
| 8 | Relative humidity | ≤85% |
| 9 | Net weight | 20kg |
| 10 | Dimension | 564mm×320mm×360mm |
| 11 | Weight of piston | 1kg±5g |
III.Accessories
| No. | Item | Unit | Qty | |
| 1 | Spare belt(Bonding after burn at both ends to soften by user self) | Piece | 1 | |
| 2 | Flushing pipe assembly |
Water absorbing skin cavity and flushing pipe |
Set | 1 |
| Latex tube (Ф7, about 1 meter) | Piece | 2 | ||
| Infusion tube spring clips | Piece | 1 | ||
| 3 | Power line (250V 6A) | Piece | 1 | |
| 4 | 2A fuse (Ф5 × 20) | Piece | 3 | |
| 5 | Funnel | Piece | 1 | |
| 6 | Test tube (With a rubber stopper) | Set | 4 | |
| 7 | Counterweight piston | Set | 1 | |
| 8 | Steel ruler (500mm, precision 1mm) | Piece | 1 | |
| 9 | Siphon pipe bending | Piece | 1 | |
| 10 | Mercury thermometer (0 ~ 50 ℃, scale division is1 ℃) | Piece | 1 | |
