| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | AI |
| إصدار الشهادات: | ISO |
| Model Number: | TOI |
| الحد الأدنى لكمية: | 1 مجموعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حالة الخشب الرقائقي |
| وقت التسليم: | 40 يومًا |
| شروط الدفع: | Western Union ، T/T ، L/C |
| القدرة على العرض: | 20 مجموعات شهريا |
| اختبار معيار: | أستم D2863، إسو 4589-2، إن إي إس 714 | Test temperature range: | 25 ºC ~ 150 ºC |
|---|---|---|---|
| Oxygen Setting Range: | 10% ~ 60% (± 0.1%) | Combustion time: | 1 second to 300 seconds |
| Ignition flame height: | 15 to 20 mm adjustable | Ignition time: | 15s ± 1s |
| Keyword: | TOI High Temperature Oxygen Index Test Apparatus | عرض: | شاشات الكريستال السائل |
Introduction:
High Temperature Oxygen Index Test Apparatus belongs to anti flaming test equipment for measuring the combustion performance of the vertical bars or 10.5mm thin plastic material under test conditions.It is also suitable for combustion performance of vertical supporting film or thin film materials .
Standards
Characteristics
1. The combustion cylinder with a heating element and a preheater.The temperature of combustion cylinder is adjustable .
2. The computer automatically controls the whole test process. The operator inputs the oxygen concentration value from the keyboard based on the test requirements. The TOI apparatus can automatically adjust the oxygen concentration value in the rangeof setting.
3. Direct detection and display of oxygen concentration value in the sample chamber.
4. Automatic ignition is safe and reliable .
5. The computer automatically handles each set of testdata,and the determining reliability of the testdata .
Technical Specifications
| 1 | Test temperature range | 25 ºC ~ 150 ºC |
| 2 | The accuracy of the test temperature | ≤125 ºC ± 2 ºC;> 125 ºC ± 3 ºC |
| 3 | The oxygen concentration setting range | 10% ~ 60% (± 0.1%) |
| 4 | The flow of oxygen, nitrogen can be controlled at the set value; the control precision | ± 0.01L / min, Resolution: 0.01L / min |
| 5 | Oxygen concentration stepsize | it can be set from 0.1% |
| 6 | Combustion time | 1 second to 300 seconds |
| 7 | Ignition flame height | 15 to 20 mm adjustable |
| 8 | Ignition timing | 15s ± 1s |
| 9 | The quartz glass burner tube dimensions | internal cylinder(inner diameter ≥75mm, height ≥450mm); outer tube ( the clearance between inner cylinder is 5mm ~ 10mm, the same height as theinternal cylinder). |
